Engine WG1903-GL

Fuel efficient
Carb Tier 3
Easy maintenance
  • Model:
  • Type:
  • Cylinders:
  • Bore and stroke:
  • Displacement:
  • Aspiration:
  • Aftertreatment:
  • Emissions:
  • Rated output:*
  • Maximum torque:*
  • Dimensions:**
  • Weight:
  • WG1903-GL
  • Vertikalni, vodno hlajeni
  • 3
  • 88,0 x 102,4 mm
  • 1,868 L
  • Atmosfersko polnjen
  • 3 stezni katalizator
  • EPA Tier 2 / CARB tier 3
  • 35,0 kW - 46,9 HP | 2700 min-1
  • 133,0 Nm | 1800 min-1
  • 551 x 534 x 701 mm
  • 167 kg
Kubota WG1903-GL

*: SAE J1995 gross intermittent
**: Dimensions do not include fan and exhaust treatment unit.
LPG - Liquid Petrol Gas: Commercial liquid propane gas only. Equivalent to propane HD-5 of GPA standard.
N - Natural gas: Commercial Compressed Natural Gas only. The performance shown is with Japanese standard CNG.. Heating value: 9699 kcal / m3

The listed engine specifications are subject to change without notice, engine dimensions and weight are listed in accordance with Kubota's standard specification. The engine series can be produced in different options so the stated specifications may deviate. The photos shown may contain non-standard equipment.

Features and benefits

Kubota WG1903 SI engines are designed after Kubota 03 Series diesel (CI) engines. While keeping the same footprint as the D1803 diesel engines, they offer performance similar to that of our turbo diesel engines, which are known worldwide as reliable industrial engines.

Emissions

Kubota’s WG1903-G engine has been designed to comply with EPA Tier 2 / CARB Tier 3 + EU Stage V.

Dimensions

Kubota WG1903-GL dimensions

Performance curves

Kubota WG1903-GL Performance curves
